CGH Cylinder Nulls are specialized holographic optical elements designed to test and verify the surface shape of cylindrical or aspherical optical components. Instead of relying on traditional mechanical reference surfaces, these devices use precisely computed holograms to create a reference wavefront. When this holographic wavefront interacts with a test surface, any deviation from the ideal shape becomes visible as an interference pattern.
The result is an immediate, high-resolution evaluation of the optical surface's accuracy, without requiring expensive mechanical null lenses. CGH Cylinder Nulls bring digital precision into optical testing—offering flexibility, repeatability, and minimal setup error.
The working principle of CGH Cylinder Nulls lies in diffractive optics. A computer-generated hologram is encoded with a phase pattern that corresponds to the ideal shape of the cylindrical optical surface being tested. When a laser beam passes through or reflects off this hologram, it generates a wavefront that precisely matches the theoretical optical shape.
When the CGH wavefront and the test surface wavefront overlap, any imperfections appear as fringe patterns. These fringes allow optical engineers to detect deviations in curvature, alignment, or surface smoothness with nanometer precision.
They eliminate the need for costly, heavy, and fragile null lenses.
They simplify the testing of complex geometries.
They deliver reliable data in less time, enhancing production efficiency.
They ensure sub-wavelength accuracy for industries such as aerospace, defense, and precision optics.
In a world where accuracy defines success, CGH Cylinder Nulls provide the bridge between design intent and real-world optical performance.
The performance of a CGH Cylinder Null depends on precise fabrication standards. Below are key specifications that define quality and performance:
| Parameter | Specification | Description |
|---|---|---|
| Material | Fused Silica / Quartz | High transparency and low thermal expansion |
| Wavelength Range | 405 nm – 1064 nm | Compatible with most interferometers |
| Surface Accuracy | λ/20 or better | Ensures sub-nanometer precision |
| Diameter Range | 25 mm – 300 mm | Customizable for different optical setups |
| Pattern Type | Binary / Multi-level | Optimized based on customer requirements |
| Mounting Option | Custom Fixture / Plate | Flexible integration with testing systems |
| Property | Value | Notes |
|---|---|---|
| Phase Accuracy | ≤ λ/50 | High fidelity to design wavefront |
| Diffraction Efficiency | ≥ 90% | Ensures strong and clean interference patterns |
| Operating Temperature | -20°C to +80°C | Stable across varying environments |
| Storage Condition | Dry, dust-free | Protects the holographic surface |
| Inspection Compatibility | Zygo, 4D, Trioptics Systems | Universally compatible with major brands |
Each CGH Cylinder Null is designed and tested with traceable calibration to international metrology standards, ensuring consistent accuracy and repeatability.
CGH Cylinder Nulls are used in diverse optical applications, including:
Cylindrical lens inspection and alignment
Aspherical mirror verification
Optical system assembly calibration
Semiconductor wafer surface evaluation
Aerospace optics production testing
Precision – Achieve nanometer-level accuracy in wavefront analysis.
Efficiency – Reduce testing time by 60% compared to traditional methods.
Cost-Effectiveness – Eliminate the need for multiple mechanical null lenses.
Flexibility – Easily customized for different optical designs.
Traceability – Compatible with industry-standard interferometers for easy integration.
